Havis Vehicle-Specific 22″ Wide Angled Console for 2021-2024 Chevrolet Tahoe Police Pursuit Vehicle C-VSW-1012-TAH

Havis Console C-VSW-1012-TAH

Havis Vehicle-Specific 22-in Wide Angled Console for 2021-2024 Chevrolet Tahoe Police Pursuit Vehicle

C-VSW-1012-TAH Features

• Fits 2021-2024 Chevrolet Tahoe PPV and SSV without OEM console
• 12.5" wide for additional accessory mounting or storage
• 22" of total equipment mounting space in 9"W section: 10" of equipment mounting space in front angled section, 12" of equipment mounting space in flat section
• 17" of total equipment mounting space in 3.3"W section: 5" of equipment mounting space in front angled section, 12" of equipment mounting space in flat section
• Mounts between bucket seats and fits to dash contour
• Includes internal front electrical equipment mounting shelf with removable front side trim panels for easy access
• Console includes provisions for internal or external side mount poles C-HDM-204 or C-HDM-214
• Two 12V DC "lighter plug" outlets with attached caps included
• See side view drawing min/max for mounting depth allowed for control heads and/or options
• Havis recommends that customers do not relocate the OEM 12V plug from the dash into the console housing for 2021-2024 Chevrolet Tahoe consoles, as improper installation may cause an electrical short (gm bulletin no. PIT5800)
• C-LPO lighter plug socket & cap is available from Havis for adding 12V plugs elsewhere in the console
• Customize to your specific needs
• Includes filler plates (FP/FPW) and/or equipment brackets (EB/EBW) to completely enclose mounting area less internal mount options for 9”W and 3.3”W sections

C-VSW-1012-TAH Specifications

Overall measurements:    12.5" high x 15.1" wide x 38.2" long (including forward trim panel)
Gross weight:    50 lbs
