Gamber Johnson Zebra ET50/51 55/56 10 Dock 7160-0860-00

Gamber Johnson Dock 7160-0860-00

Zebra ET50/51 55/56 10 Docking Station. The tablet’s scanner; hand strap; battery bay; and stylus all work with the docking station. This dock features a powered RS232 port to connect hand-held or mobile computers; scales; scanner guns; or printers. Additional ports include Ethernet; USB 3.0; and power input.

7160-0860-00 Features

• Port replication
• Designed and tested for MIL-STD 810G specifications
• Compatible with Zebra enterprise tablets with the rugged frame option
• Accommodates the expansion back of the ET50/51 55/56 to easily add accessories like a scanner/ hand strap and optional battery bay or hand strap and optional battery bay
• Front camera on ET5X accessible when the tablet is in the docking station
• Compatible with Windows or Android operating systems
• Dual latch/locks provide added stability and docking connectivity
• Guide pins prevent damage to the docking connector when docking the tablet
• VESA 75mm mounting pattern
• Steel and Composite design for reduced overall weight
• Rugged construction for long-term durability

7160-0860-00 Specifications

Weight

2.6 lbs / 1.18 kg

Height

10.0 in / 25.4 cm

Width

9.0 in / 22.9 cm

Depth

3.35 in / 8.5 cm

Port Replicators:

RS232 serial power on pin 9 - 1 amp
Power input
USB (1.1A charging)
USB 3.0
Ethernet RJ45 (1)

Antenna Pass-through:

No RF
