Havis Dock for Dell’s 7030 Tablet with Advanced Port Replication & Internal, Non-isolated Power Supply DS-DELL-1102

Havis Dock DS-DELL-1102

Havis Docking Station for Dell 7030 Tablet with Advanced Port Replication and Internal, Non-isolated Power Supply

DS-DELL-1102 Features

• Supports Dell's 10” Latitude 7030 Rugged Extreme Tablet in Warehouse & Distribution, Energy & Utilities, Public Safety, and other demanding environments
• Advanced port replication includes video capability as well as standard options to support mission-critical peripherals
• Side-mounted USB3.0 port
• LED power indicator
• One-handed docking & undocking
• Spring-loaded, floating docking connector head ensures connectivity even through heavy vibration
• Internal, non-isolated power supply (9-36V)
• Provides access to all buttons, ports, and bar code scanner when tablet is docked
• Compatible with Dell 7030 tablet accessories including hard and soft handles, magnetic mount, rotating hand strap and shoulder strap
• Compact & lightweight
• Integrated cable management system
• Integrated VESA 75 mounting pattern
• Polycarbonate construction ensures strength, ruggedness and extreme temperature resistance
• Rounded edges and corners for comfort and safety
• Keyed lock for added security
• Made in USA

DS-DELL-1102 Specifications

Compatible computer:    Dell 10” Latitude 7030 Rugged Extreme Tablet
Certifications:    Vibration Testing: MIL-STD 810H 514.8 Crash Testing: SAE J1455 30mph Cycle Testing: Latch handle and docking connectors 30K cycles Environmental Testing: Hot/Cold operational -29° C to 63° C (-20° F to 145° F); Hot/Cold storage -40° C to 85° C (-40° F to 185° F)
Port Replication:    (1) RJ45 Ethernet, (3) USB3.0 Type A, (1) USB-C, (1) DB9 Serial - 5V powered, (1) HDMI, (1) DC In port
Dimensions:    Height 9.14” (232mm) latched, 9.64” (245mm) unlatched; Width 9.5” (241mm); Depth 3.45” (88mm)
Product weight:    2.26 lbs (1.03kg)
Gross weight:    2.75 lbs
